A2001(PH)alternative PH 2.00 Housing Terminal Cable Wafer
Product detailsSpecifications:
Rated current: 2A AC, DC
Rated voltage: 125V DC
Temperature range: -40 deg C to +105 deg C
Contact resistance: 20m Omega Max.
Insulation resistance: 1000M Omega Min.
Withstand pressure: 800V AC/minute
Housing: PA66 94V-0 Whiter/black
Terminal material: phosphor copper tin plating
DIP pin body material: PA66 94V-0 White
SMT pin body material: LCP 94V-0 natural color
PIN material: brass tin plated
Pin holder ground disc material: brass tin plated
