A2016(55460)alternative 55460 Housing Terminal Cable Wafer
Product detailsSpecifications:
Rated current: 3A AC, DC
Rated voltage: 125V DC
Temperature range: -40 deg C to +105 deg C
Contact resistance: 10m Omega Max.
Insulation resistance: 1000M Omega Min.
Withstand voltage: 1000V AC/minute
Housing: PA66 94V-0 White/Grey
Terminal material: phosphor copper tin plating
DIP pin holder body material: PA6T 94V-0 White
SMT pin holder body material: PA6T 94V-0 Beige
PIN Pin material: brass tinned
Pin base earth plate material: brass tinned
