A1005(NH)Buckle alternative NH 1.00mm Crimp Terminal Housing
Product detailsSpecifications:
Rated current: 1A AC, DC
Rated voltage: 50V DC
Temperature range: -25 deg C to +105 deg C
Contact resistance: 20m Omega Max.
Insulation resistance: 100M Omega Min.
Voltage: 500V AC/minute
Housing: PA66 94V-0 white
Terminal material: phosphor copper tin/gold plated
Pin body material: PA6T 94V-0 beige
PIN Pin material: phosphorus copper tin plating
Pin holder ground disc material: brass tin plated
